Item Number Description Part Number Quantity 1 Printhead 203 dpi ZT411 & ZT411 RFID that is NOT printing On-Metal RFID labels P1058930-009 1 1 Printhead 300 dpi ZT411 & ZT411 RFID that is NOT printing On-Metal RFID labels P1058930-010 1 1 Printhead 600 dpi ZT411 & ZT411 RFID that is NOT printing On-Metal RFID labels P1058930-011 1 1 Printhead for On-Metal RFID label printing applications 203 dpi ZT411 P1105147-300 1 1 Printhead for On-Metal RFID label printing applications 300 dpi ZT411 P1105147-301 1 1 Printhead 203 dpi ZT421 & ZT421 RFID P1058930-012 1 1 Printhead 300 dpi ZT421 & ZT421 RFID P1058930-013 1 2 Thermal Transfer Print Mechanism ZT411 (includes ribbon sensor with cable, printhead cables, ground contact and magnets) P1105147-005 1 2 Thermal Transfer Print Mechanism ZT421 (includes ribbon sensor with cable, printhead cables, ground contact and magnets) P1105147-006 1 3 Toggle Bar (includes lift strap) ZT411 P1058930-104 1 3 Toggle Bar (includes lift strap) ZT421 P1058930-107 1 Ribbon Strip Plate and Ribbon Static Brush ZT411 P1058930-094 1 Ribbon Strip Plate and Ribbon Static Brush ZT421 P1058930-095 1 Magnets for holding the Print Mechanism open P1058930-082 1 Ground Contact ZT400 Series P1058930-083 1
Number Description Part Number Quantity Convert to 300 dpi ZT411 P1058930-022 1 Convert to 203 dpi ZT411 P1058930-023 1 Convert to 600 dpi ZT411 P1058930-024 1 Convert to 300 dpi ZT421 P1058930-025 1 Convert to 203 dpi ZT421 P1058930-026 1
Item Number Description Part Number Quantity 1 Platen Roller ZT411 P1058930-080 1 1 Platen Roller ZT421 P1058930-081 1 1 Kit, Replacement Linerless Media Platen Roller, ZT411 P1105147-701 1 2 Lock/Retainer for the Platen Roller ZT400 Series P1058930-027 1 3 Coupler for Platen Roller ZT400 Series 79862M 1
Item Number Description Part Number Quantity 1 Dual Port USB PCBA ZT411 ZT421 P1058930-403 1 2 Power Supply ZT411 P1105147-012 1 2 Power Supply ZT421 P1105147-024 1 3 Standard Main Logic Board ZT411 ZT421. (Standard printer models have control panels with USB ports) P1105147-007 1 3 Economy Main Logic Board ZT411 ZT421. (Economy printer models have control panels without USB ports) P1105147-008 1 Mounting Bracket for the Main Logic Board ZT411 ZT421 P1105147-009 1 4 ZebraNet Internal Wireless 802.11 ac radio, BT4.0, ZT411 ZT421 USA & Canada. P1083320-037A 1 4 ZebraNet Internal Wireless 802.11 ac radio, BT4.0, ZT411 ZT421 Japan. P1083320-037B 1 4 ZebraNet Internal Wireless 802.11 ac radio, BT4.0, ZT411 ZT421 for all countries except USA, Canada or Japan. P1083320-037C 1 5 Internal Printserver (Ethernet port) ZE511, ZE521. ZT400 Series P1058930-074 1 6 Parallel Port ZT400 Series P1058930-075 1 7 RFID Module USA & Canada ZT400 Series P1058930-500A 1 7 RFID Module Japan ZT400 Series P1058930-500B 1 7 RFID Module Global (All countries except USA, Canada, Japan) ZT400 Series P1058930-500C 1 Applicator Interface Card P1083320-038 1 Replacement RFID Cables and Hardware ZT400 Series P1058930-503 1 Light Assemblies (Includes 1 Print Mechanism Light & 1 Media Light) P1058930-079 2 Replacement Antenna for 802.11n & ac Radios P1037974-053 1 Electronics Cables ZT411 ZT421 P1105147-013 1 USA Power Cord 46693 1 Europe Power Cord 46629 1 UK Power Cord 46637 1 Japan Power Cord 37609 1 China Power Cord 47612 1
Item Number Description Part Number Quantity 1 Media Sensor ZT411 P1105147-014 1 1 Media Sensor ZT421 P1105147-015 1 2 Head Open Sensor ZT411 ZT421 P1058930-084 1 3 Ribbon Sensor ZT411 P1105147-016 1 3 Ribbon Sensor ZT421 P1105147-017 1 4 Take Label Sensor ZT411 ZT421 P1105147-018 1
Item Number Description Part Number Quantity 1 Drive System ZT400 Series (includes gears, belts and pulleys for 203 dpi and 300/600 dpi) P1058930-039 1 2 Drive Motor ZT400 Series P1058930-040 1 3 Drive Belt 203 dpi ZT400 Series 79866M 1 3 Drive Belt 300 dpi and 600 dpi ZT400 Series 79867M 1
Item Number Description Part Number Quantity 1 Standard Media Hanger for 3" (76mm) diameter media cores ZT411 P1058930-042 1 Media Hanger for 1" (25mm) diameter media cores ZT411 only P1058930-086 1 1 Standard Media Hanger ZT421 P1058930-043 1 2 Ribbon Supply Spindle ZT411 P1058930-085 1 2 Ribbon Supply Spindle: For Ribbons Coated Inside Only ZT411 79830M 1 2 Ribbon Supply Spindle ZT421 79829M 1 3 Ribbon Take Up Spindle ZT411 P1058930-045 1 3 Ribbon Take Up Spindle ZT421 P1058930-046 1 4 Media Dancer ZT411 P1105147-025 1 4 Media Dancer ZT421 P1105147-026 1 5 Standard Media Guides and Media Carrier ZT411 P1105147-027 1 5 On-Metal RFID Media Guides and Media Carrier ZT411 P1105147-302 1 5 Media Guides and Media Carrier ZT421 P1105147-028 1 6 Media Shelf ZT411 P1058930-047 1 6 Media Shelf ZT421 P1058930-048 1 7 Tear Bar ZT411 79837M 1 7 Tear Bar ZT421 79838M 1 Covers for the Media Light holes on Economy models without Media Lights P1105147-010 4
Item Number Description Part Number Quantity 1 Cutter Option ZT411 P1058930-189 1 1 Cutter Option ZT421 P1058930-190 1 2 Peel Assembly ZT411 P1105147-019 1 2 Peel Assembly ZT421 P1105147-020 1 3 Liner Take Up Spindle & Motor ZT411 (To enable liner take up functionality, also purchase the P1105147-019 peel assembly) P1058930-052 1
Item Number Description Part Number Quantity 1 Catch Tray for Cutter ZT411 77041 1 1 Catch Tray for Cutter ZT421 77997 1 2 Cover for the Cutter includes PCBA and cutter cable ZT411. P1058930-102 1 2 Cover for the Cutter includes PCBA and cutter cable ZT421. P1058930-103 1 4 Kit, Replacement Cover with PCBA for the Linerless Cutter, ZT411 P1105147-702 1 3 Replacement Static Brush & Cutter Guard ZT411. P1066612 1 3 Replacement Static Brush & Cutter Guard ZT421. P1066613 1 4 Kit, Replacement Linerless Media Cutter Assembly, ZT411 P1105147-703 1 5 Kit, Replacement. Linerless Media Latch Assembly and Cutter Mounting brackets, ZT411 P1105147-704 1
Item Number Description Part Number Quantity 1 Roller for the Peel Assembly ZT411 77197M 1 1 Roller for the Peel Assembly ZT421 77727M 1
Item Number Description Part Number Quantity 1 Motor and PCBA for Liner Take Up Spindle ZT411 G34112M 1
Item Number Description Part Number Quantity 1 Media Guard for Media Rewind Spindle ZT400 Series P1058930-057 1 2 Media Rewind Spindle (includes Motor and PCBA) ZT411 (This item is only for replacing an existing media rewind spindle on a printer that shipped from the factory with the media rewind option installed. Media rewind is not a field installable option) P1058930-058 1 2 Media Rewind Spindle (includes Motor and PCBA) ZT421 (This item is only for replacing an existing media rewind spindle on a printer that shipped from the factory with the media rewind option installed. Media rewind is not a field installable option) P1058930-059 1 Motor and PCBA for Media Rewind Spindle ZT411 G34110M 1 Motor and PCBA for Media Rewind Spindle ZT421 G34111M 1 Steer Roller for Media Rewind ZT411 P1058930-055 1 Steer Roller for Media Rewind ZT421 P1058930-056 1 Door and Trim for Media Rewind ZT411 P1058930-060 1 Door and Trim for Media Rewind ZT421 P1058930-061 1
1 Covers/Mounts for Options ZT400 Series P1058930-062 1 2 Kit,Bracket,Cord,ZT4X1 (Set of 5) P1105147-038 5 Assorted Hardware ZT411 ZT421 (various screws and washers used throughout the printer) P1105147-023 1 Feet on bottom of printer (Qty 20) ZT400 Series P1058930-078 20
